The Power Supply and sealing coil is mounted to portable cart for easy mobility from line to line
induction Sealer | automatic induction cap sealer | Induction Cap Sealing Machine | Capping Machine | bottle top sealers | Cap Seal Liners | Induction Heat Seal Liner
APPLICATION ⇒
♦ Suitable for non-metal containers: .
Glass or plastic bottles - ABS, PE (HDPE, LDPE), PET, PP, PS, PVC.
♦ Suitable for screw caps, tamper-proof caps, etc.
♦ Suitable for any product in the container:
Medicine-Powder, Lotion, Capsule, Ingot & etc.
Food-Jelly, Fish food & etc.
Beverages-Water, Milk, Juice, Yogurt & etc.
Cosmetic-Skimmed milk, Lotion & etc.
Chemical-Alcohol, Cleaner & etc.
Others-Engine oil, Machine oil & etc.
♦ Bottle cap Outer Diameter:
10~55 mm or 20~120 mm (Special customized cap size acceptable).
FEATURES ⇒
♦ Highly efficient sealing function, capable of complete sealing
in spite of small quantity of water, oil stains or powders on the bottle opening.
♦ Provided with "Aluminium detection devices"
to detect any aluminium foil inside the bottle cap, it will alarm automatically
or trigger the "Removal system in absence of aluminium foil" to remove cap &
to prevent non-conforming products without sealing from access to the product line.
♦ The product is equipped with the current overload beeper,
the failure beeper & operation indicator lamps to ensure safe operation.
♦ Simple design & adjustable to suit vessels of various sizes & heights.
♦ Adopts imported solid power crystal assembly & the modulated design
to ensure low failure rate, convenient maintenance & low energy consumption.
♦ The power & control cables adopt quick jacks, to allows easy assembly & disassembly.
♦ Adopting IGBT/MOS-FET modulated design
to provide with low failure rate, reduced loss rate and doubled efficiency.
♦ Sealing of vessels with different height can be achieved by adjusting the inductor.
SPECIFICATION ⇒
Model | AF-2000W |
Voltage | 220V, single phase |
Power | 2000 W |
Maximum current | 12 A |
Cap dimension | 10~55 or 20~120 mm |
Sensor | Air cooled |
Generator type | MOS-FET |
Frequency | 50~100 kHz |
Generator size | 340 x 218 x 330 mm |
Inductance coil | 500 x 120 x 120 mm |
Net weight | 110 kg |
