PRODUCT > HORIZONTAL FLOW WRAPPING MACHINE JE 535
Horizontal Form Fill Seal Machine - Flow Wrapper
JE-535
Horizontal Form Fill Seal Machine - Flow Wrapper


APPLICATION  ⇒

♦  Chocolate bar, biscuits, bread;
♦  Frozen food, instant noodle;
♦  Machine parts, tools, phone cards & etc.

Model No. JE-535 JE-547 JE-561
Capacity (PPM) 20~230 20~180 15~100
Bag Length (mm) 60~350 100~450 150~500
Max. Film Width 350 mm 470 mm 610 mm
Max. product Dimension W 145 mm 190 mm 270 mm
H 60 mm 60 mm 80 mm
Electricity AC220V - single phase

DESCRIPTION  ⇒
Standard Asian mechanical wrapper (
30 years professional & sales over 30 countries)
♦  4 sets of temperature controller
♦  Electric bag length adjustment
♦  Print mark registration fixed bag former
♦  Top brush belt
♦  Fixed bag former
Optional:
♦  Adjustable bag former & date Coder

FEATURES  ⇒
♦  PID temperature controller
♦  Germany “sick” mark sensor
♦  PLC progam control
♦  Powder coation machine frame
♦  Mark Auto reset button for film replacement
♦  Timing belt transmmision

OPTIONAL ACCESSORY
♦  End seal gusset
♦  In-feed carrier block
♦  Auto labeling device
♦  Additional reel holder
♦  Transfer belt between center sealer & end sealer
♦  Transfer chain conveyor on the end sealing station
♦  Gas flushing device
♦  Cards auto feeder
♦  Auto feeding system
