LABEL FORM ⇒
FEATURES ⇒
♦ Label made by China material can be used, it reduces many label cost.
& pressing equipments to make the bottles steady.
♦ It won't be effected by the objects' precision.
♦ It can save 8 kinds of labeling information, it doesn't need to debug & move the
magic eye again when you change the labeling containers.
♦ The touching display, simulant capacity adjustment & it has easy mecanical
adjustment, need not the professional technical worker to operate.
♦ It has the show of the day and total quantity.
♦ It can use stand-alone or join the production line.
♦ Adopt import electirc components.
♦ Adopt 304 stainless sstell & alloy which is dealed with anodic oxidation except
the shelf
SPECIFICATION ⇒
Model | J500 |
Object to apply | Columniform containers with one sticker or two stickers |
Container range (W x H) | ∅25~120 x 25~300 mm |
Label range (L x H) | 15~380 x 15~130 mm |
Label speed | 0-80 pcs/min |
Label precision | ±1 mm; Top to down: ±0.5 mm |
Power | 0.25kW, 220V, 50/60HZ |
Air power | 5kg/cm² |
Machine dimension (L x W x H) | 1,600 x 1,100 x 1,300 mm |
Machine net weight | 150 kgs |
**** We can customize your order if you have special demands. ****
